Q Acoustics E60 In Wall Bluetooth Amplifier

The Q Acoustics E60 is a discreet in-wall audio amplifier designed to deliver high-quality sound in any room of the home.

Built for easy installation and seamless integration, it combines Bluetooth streaming, an optical input for TV audio and a clean, zero-clutter wall-mounted design.

Ideal for bathrooms, kitchens, bedrooms and garden rooms, the E60 offers reliable performance in environments where space, simplicity and durability matter.

Designed as part of Q Acoustics’ easy install range, the E60 features a built-in Class D amplifier delivering 2 x 25 watts of power. It can drive up to two pairs of in-ceiling or cabinet speakers, making it a flexible solution for both compact and larger spaces.

With IP54 splash-proof protection and touch-sensitive controls, it is equally suited to humid areas and everyday family use.

FEATURES

• Built-In 2 x 25W Class D Amplifier: Delivers clean, controlled and dynamic sound with low distortion across a 20Hz–20kHz frequency response. Powerful enough to drive up to two pairs of speakers, it provides flexibility for single-room or wider coverage setups.
• Bluetooth 5.0 Streaming: Stream music wirelessly from smartphones, tablets and laptops using Bluetooth 5.0 with AVRCP control for play, pause and track skip. A simple and reliable way to enjoy everyday audio.
• Optical Input For TV Audio: The TOSLINK optical input supports 16bit/48kHz audio, allowing straightforward connection to a television or external source. Enhance TV sound without adding bulky equipment.
• Touch-Sensitive Glass Controls: Nine responsive touch buttons provide intuitive operation, even with wet fingers. LED indicators brighten during adjustments and gently dim afterwards for a discreet finish.
• IP54 Splash-Proof Design: Ready for bathrooms and kitchens straight out of the box, the IP54-rated wall panel requires no additional sealing. This makes it a dependable choice for humid environments without complicating installation.
• Stereo Or Dual Mono Operation: Switchable mono mode allows both channels to play through both speakers. Ideal for bedroom and bathroom combinations or open-plan areas where consistent sound coverage is more important than stereo positioning.
• Analogue Line Output: A fixed or variable 3mm line output enables connection to a subwoofer or additional amplifier. Expand and tailor the system without replacing the core setup.
• Installer-Friendly Design: Supplied with speaker cables and DC extension, and powered by standard socket outlet, the E60 is designed to reduce installation time while maintaining a clean, modern appearance.

Whether you are upgrading a bathroom, adding music to a kitchen or creating a simple whole-room audio solution, the Q Acoustics E60 delivers dependable performance in a compact, elegant format.

• Audio Sources: Wireless: Bluetooth (BT 5.0, A2DP)
• AUX: Optical TOSLINK, Resolution: 16bit 48kHz
• Speaker Outputs: Left & Right, Stereo or dual mono
• Analogue Line: 3mm stereo, Modes: Fixed or variable, Max level: 670mV
• Amplifier Type: Class D, Continuous power: 2 x 25W @ 6Ω, THD: 0.07% @ 1W, 0.2% @ rated power, SNR: >75dB @ rated power, Frequency response: 20Hz - 20kHz +/- 1dB
• Ratings: E60 wall panel: IP54
• Control: Touch sensitive buttons: x9, BT AVRCP v1.6 (play, pause, skip, track)
• Power Supply: Input: 100 - 240V AC 50/60Hz, Output: 22V DC 1.5A, Dimensions (HxWxD): 30mm x 50mm x 115mm
• Power Consumption: Typical: 10W, Standby: <2W
• Wall Panel: Net weight: 1.3kg, Dimensions (HxWxD): 91mm x 151mm x 33mm, Operating ambient temperature: Max. 40ºC
• Speaker Cable: Gauge: 19 AWG, Lengths: 2 x 7m
• DC Extension: Gauge: 16 AWG, Length: 5m, Connectors: 6mm x 2mm DC male, 6mm x 2mm DC female

• 1 x Amplifier Wall Panel
• 1 x Mounting Frame
• 1 x 5M DC Extension Cable
• 1 x Power Supply
• 2 x 7.5m Speaker Cables
